Wisenet XNV-9083RZ 8MP AI Vandal Dome Camera

The Wisenet XNV-9083RZ is a 8-megapixel dome camera with 4.4 ~ 9.3mm (2.1x) motorised varifocal lens. The lens provides a 113° ~ 47° horizontal field of view, enabling users to select the best area of coverage within these parameters for their application.

As well as this the unit features AI (artificial intelligence) analytics, and the analytics events are based on AI engine:

– Object detection (person, face, vehicle – car, truck, bus, bicycle, motorcycle, license plate)

– IVA (virtual line, area enter and exit, loitering, direction, intrusion)

Other analytics include:

– Defocus detection

– Motion detection

– Tampering detection

– Fog detection

– Audio detection

– Sound classification

– Shock detection

– Appear/disappear

The XNV-8083RZ has been designed for outdoor use with its IP66/IP67/IP6K9K and IK10+ rating housing. This housing protects the camera against both harsh outdoor weather conditions and vandal attempts.

---

Please Note: we are aware of growing concern for public safety and privacy regarding CCTV cameras. Hanwha Europe has stated: “To be clear, Hanwha doesn’t offer a live facial recognition solution in Europe. And, as a Korean NDAA-compliant manufacturer with complete control over its supply chain and a strong background in cyber security, we are strong advocates for the responsible use of video surveillance technology”.

---

DORI

This is a standard system used to define the ability of a camera to distinguish persons or objects within a covered area. The maximum distance at which a camera/lens combination can meet these criteria is shown below:

Detect	Observe	Recognise	Identify
51.7 ~ 176.6m	20.3 ~ 70.7m	10.2 ~ 35.3m	5.1 ~ 17.7m

---

Packing List:

– XNV-9083RZ x 1

– Mounting template x 1

– Sunshield x 1

– Installation guide x 1

– L-wrench x 1

– Cable bush x 2

– Cap installer x 1

---
